SAM750 Mobile Stage Rental
Stageline's largest mobile stage: 70' x 56' with a 52-foot trim height and 152,000 lb of rigging, for national-scale productions.
Equipment RentalsStaging EquipmentMobile StagesSAM750
Stageline SAM750
The SAM750 at a Glance
The SAM750 is a stadium-scale roof system on wheels: a 52-foot trim height, 75 tons of rigging capacity and huge LED screen positions, with covered wings, a crossover and a hydraulic loading ramp.
It is built for the biggest outdoor concerts and festivals. Setup takes about 16 hours with a crew of 12, and Stageline recommends it for audiences of well over 10,000.
SAM750 Specifications
- Stage floor70' x 56', plus two covered wings 28' wide
- Trim height52'
- Total rigging capacity152,000 lb (75 tons)
- Setup timeAbout 16 hours with a crew of 12
- Recommended audienceOver 10,000
- Wind rating115 mph without windwalls, 77 mph with windwalls (manufacturer's rating)
- Crossover, ramp and dock129' x 14' with an 8' x 50' hydraulic ramp
- LED screen riggingSide screens 25' x 53', upstage 60' x 40', optional header
Specifications are Stageline’s published figures. Exact footprint, options and setup time depend on your site and configuration.
What the SAM750 Is Built For
Typical events for this size of stage.
Stadium-scale concerts
Outdoor shows at the size of a stadium tour.
Headline festivals
Main stages for the largest festivals.
National productions
Broadcast and national events that need a showpiece stage.
Options and Add-Ons for the SAM750
Build the stage out to fit your show.
- Covered wingsTwo covered wings for production and backline.
- Crossover and hydraulic rampTruck-height loading straight onto the stage.
- LED screensSide, backdrop and optional header screen positions.
- Stageline-certified setupDelivered, set up and struck by our certified technicians.
- Barricade, power and accessFront-of-stage barricade, power distribution and ADA platforms.
- CrewStagehands, riggers and AV technicians for the rest of the build.
Compare Our Mobile Stages
From a 20-foot community stage to a 70-foot stadium roof.
SAM750 Rental FAQ
SAM750 Questions
Is setup included when I rent the SAM750?
Yes. Every SAM750 rental is delivered, set up and struck by our Stageline-certified technicians, so you do not need to supply stage labor.
How big is the SAM750?
Stageline lists the SAM750 stage floor as 70′ x 56′, plus two covered wings 28′ wide. We confirm the full footprint, including wings and access, for your site during planning.
Where can I rent the SAM750?
We deliver mobile stages across Utah and Arizona, including Salt Lake City and the Phoenix Valley, and travel further for touring work. Ask about your date and location.
Can I add sound, lighting and video?
Yes. We rent audio, lighting and LED video packages, power distribution and barricade alongside the stage, and can supply the crew to run it all.
Check SAM750 Availability
Send your date, location and expected crowd size and we will confirm availability and send a quote.
